| Vehicle Main Dimensions | (L x W x H)mm | 9300x2500x3950 |
| Wheel base (mm) | 3825+1350 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
| Approach/Departure angle(°) | 16/24 | |
| Weight in KGS | Tare Weight | 13500 |
| Loading Capacity | 30000 | |
| Front axles loading capacity | 1×9500 | |
| Rear axles loading capacity | 2×16000 | |
| Engine | Brand | WEICHAI |
| Model | WP12.400E201 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power（HP) | 400 | |
| Emission standard | Euro Ⅱ | |
| Gearbox | HW19710 , 10 forwards & 2 reverse | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Steering Gear | BOSCH, power steering, hydraulic steering with power assistance | |
| Fuel tank (L) | 400 | |
| Tire | 12R22.5 Tubeless Radial Tyre, 11 pieces including one spare tire | |
| Brakes | Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake |
|
Mixer Body
|
Thickness |
End plate | 6mm high tensile strength steel |
| Mixer body | 5 mm high tensile strength steel | |
| Mixer body Volume | M3 | 10 M3 |
| Hydraulics | Motor, Pump | ARK brand |
| Gear box | TOP brand |
