| Name |
F2000 Dump Truck |
| Drive Type |
6×4 |
| Curb Weight(kg) |
11200 |
| Rated Payload(kg) |
13670 |
| Gross Vehicle Weight(kg) |
25000 |
| Maximum Speed(km/h) |
77 |
| Dimensions(mm) |
8275×2490×3450/8545×2496×3370 |
| Wheelbase(mm) |
3800+1350 |
| Front/Rear Overhang(mm) |
1525/1600 |
| Track Width(mm) |
1939/1800 |
| Engine Model |
Steyr Engine WD615.50, 290 hp, Euro II Emission Standard |
| Rated Output Power |
213 kW |
| Torque(N·m/rpm) |
1160/1100-1600 |
| Displacement(L) |
9.726 |
| Fuel Tank Capacity |
380 |
| Tires |
11R22.5 |
| Clutch |
φ430 diaphragm spring clutch |
| Transmission |
9JS135 type, 9 forward gears + 1 reverse gear |
| Front Axle |
MAN 7.5-ton front axle |
| Drive Axle |
STR 13-ton × 2 axles, speed ratio 5.73 |
| Steering System |
ZF technology (left-hand drive) |
| Braking System |
The service brake is a dual-circuit air brake; the parking brake is a power spring brake acting on the front and rear wheels |
| Cabin |
Delong F2000 lengthen-flat top cab, single bed with A/C, Manual window lifter |
| Cargo Box Dimensions (mm) |
5600×2300×1400, floor 8 mm, side panels 6 mm |
| Lifting type |
Mid-mounted Dual Hydraulic Cylinder Lifting |
