| Name |
HOWO NX440 Dump Truck |
| Model |
ZZ3257V384E1 |
| Drive Type |
6×4 |
| Curb Weight(kg) |
9500 |
| Rated Payload(kg) |
32000 |
| Gross Vehicle Weight(kg) |
41500 |
| Maximum Speed(km/h): |
80 |
| Dimensions(mm) |
8600×2550×3600mm |
| Wheelbase(mm): |
3825+1350mm |
| Front/Rear Overhang(mm) |
1500mm / 1870mm |
| Engine Model |
MC11.44-50 |
| Rated Output Power |
324 kW |
| Torque(N·m/rpm) |
1900N・m/1000-1400rpm |
| Displacement(L) |
10.5 |
| Fuel Tank Capacity |
400 |
| Tires |
12.00R20 18PR |
| Clutch |
430mm dry diaphragm clutch (hydraulic power assist) |
| Transmission |
HW20716，16 forward gears + 2 reverse gears |
| Front Axle |
VGD95 |
| Drive Axle |
AC16/HC16, speed ratio 5.26 |
| Braking System |
Dual-circuit air brakes (front disc/rear drum / all drum) + WABCO ABS anti-lock braking system
Parking brake: Spring-operated (air-stop brake) |
| Cabin |
lengthen-flat top cab, single bed with A/C, Manual window lifter |
| Cargo Box Dimensions (mm) |
5600×2350×1500mm |
| Lifting type |
Center lift |
