Rated Power（Kw):65 Dimension (L*W*H):6503*2050*2898/ 6696*2050*2898 Discharge height:3300/4500mm Discharge distance:1040/935mm
| Bucket Capacity | m3 | 0.9/1.2 | |
| Rated load | T | 2/1.2 | |
| Engine | Model | 4100GBZ | |
| Producer | YunNan | ||
| Min Fuel Consumption g/kw.h | 225 | ||
| Rated Power kw | 65 | ||
| Rated Speed r/min | 2400 | ||
| Operating Weight | kg | 5200 | |
| Max Discharge Height | mm | 3300/4500 | |
| Max Discharge Distance | mm | 1040/935 | |
| Wheel Base | mm | 2490 | |
| Wheel Track | mm | 1600 | |
| Minimum Ground Clearance | mm | 369 | |
| Steering Angle | ° | 35 | |
| Dimension (Length * Width* Height) | mm | 6503*2050*2898/ 6696*2050*2898 | |
| Departure Angle | ° | 30 | |
| Max Traction Force | kN | 46 | |
| Turning Radius | mm | 5640（4953） | |
| Max Climbing Capacity | 30 | ||
| Htdraulic Cycle Time | s | 8.96 | |
